Description
| Type | MK 8-03N |
|---|---|
| Order no. | MK00803N |
| GTIN | 7611682008470 |
| PE | 1 |
| VE | 1 |
| EU custom tariff number | 85256000 |
| Inputs | |
|---|---|
| Number of tuners | 8 × DVB-S/S2/S2X |
| Connector | 8 × F-female |
| Frequency range | 900 … 2150 MHz @ DVB-S/S2/S2X |
| Input level | 43 … 84 dBµV @ DVB-S/S2/S2X |
| LNB voltage | 13/17 V; 22 kHz on/off; DiSEqC 1.0 |
| Max. LNB current | 250 mA per input 1000 mA per device |
| CI slots | 3 |
| Input modulation | |
| Type | QPSK/8PSK/8APSK/16APSK/32APSK @ DVB-S/S2/S2X |
| Compliance | DVB-S = EN 300 421 DVB-S2 = EN 302 307-1 v1.4.1 DVB-S2X = EN 302 307-2 v1.1.1 |
| Supported input transport streams | MPEG-2 ISO/IEC 13818 | MPEG-4 ISO/IEC 14496 |
| Error correction | auto |
| Symbol rate | 1.5 … 45 MS/s (< 40 MS/s in 32APSK) |
| Transportstreams | |
| Modifiable program information | Program name, SID remapping, PID remapping, PID filtering* TSID, ONID |
| LCN | Yes |
| NIT handling @ DVB-C | auto | off | manual* |
| Encryption | DVB-CSA*, DVB-CISSA*, ATIS-IDSA*, AES-ECB*, AES-CBC* |
| Output | |
| Number of channels | 8 × DVB-C/DVB-T |
| Frequency range | 109 … 1006 MHz @ DVB-C 109 … 862 MHz @ DVB-T |
| Channels selectable | S2…K87 @ DVB-C S2…K69 @ DVB-T |
| Channel bandwidth | 7/8 MHz @ DVB-T |
| Possible frequency shift | –4 … +4 MHz (0,5 MHz steps) |
| Connector | 1 × F-female |
| Impedance | 75 Ω |
| Output level adjustable | 75 … 95 dBµV @ DVB-C/DVB-T |
| Output modulation | |
| Compliance | DVB-T (EN 300 744) DVB-C (EN 300 429/ITU-TJ.83 Annex A/C) |
| Type | QAM16, QAM32, QAM64, QAM128, QAM256 @ DVB-C QPSK, QAM16, QAM64 @ DVB-T |
| MER | ≥ 40 dB @ DVB-C ≥ 36 dB @ DVB-T |
| Bit rate, max | 50.87 Mbps @ DVB-C | 31.668 Mbps @ DVB-T |
| FFT | 2K mode @ DVB-T |
| FEC | 1/2, 2/3, 3/4, 5/6, 7/8 @ DVB-T |
| Guard interval | 1/4, 1/8, 1/16, 1/32 @ DVB-T |
| Symbol rate | 1 … 7.5 MBaud/s |
| Interfaces | |
| Ethernet connectors | 1 × RJ 45 |
| Ethernet standards | IEEE 802.3, 100 Base-T |
| Supported configuration protocols | HTTP, SNMP v1, SNMP v2c, AXING SMARTPortal** |
| General | |
| Operating temperature range (acc. to EN 60065) | –10°C…+50°C |
| Operating voltage | 100 … 240 VAC/50 … 60 Hz |
| Power consumption | 50 W |
| Equipotential bonding connection | 4 mm² |
| Dimensions (W × H × D) appr. | 436 × 253 × 47 mm |
| Weight | 2.600 kg |
| Comments | * with software extension only ** encrypted, cloud-based application for configuration, monitoring and remote maintenance |
