Description
| Type | ORX 1310-00 |
|---|---|
| Order no. | ORX131000 |
| GTIN | 7611682009941 |
| PE | 1 |
| VE | 1 |
| EU custom tariff number | 85291095 |
| Output | |
|---|---|
| Frequency range | 5 … 204 MHz |
| Output level | 100 dBµV |
| Connector | 4 × F-female |
| Test port | 4 × F-female (–20 dB) |
| Impedance | 75 Ω |
| Return loss | ≥ 16 dB |
| RFoG | |
| Input wavelength | 1100 … 1600 nm |
| Input level | −22 … 0 dBm |
| Input AGC range | –10 … 0 dBm |
| Connector Input | 4 × SC/APC |
| Return loss input | > 45 dB |
| Interfaces | |
| Ethernet connectors (LAN) | 1 × RJ 45 |
| Ethernet standards | IEEE 802.3, 100 Base-T |
| RF connectors | |
| Type | F-female |
| Interfaces | |
| Supported configuration protocols | HTTP |
| General | |
| Operating voltage | 90 … 250 VAC / 50 … 60 Hz |
| Power consumption | 20 W |
| Operating temperature range | −20 … +45 °C |
| Dimensions (W × H × D) appr. | 480 × 43 × 365 mm |
| Weight | 2.6 Kg |
