Description
| EMV | according to EN 50083-2, Class A |
|---|---|
| Frequency range | 47…862 MHz |
| Reinforcement | 25 dB |
| Max. output level CSO/CTB (CENELEC grid, 41 channels, 60 dB IMA) | 98 dBµV |
| Attenuation: stepless level control | 0…20 dB |
| Equalization: stepless level control | 0…18 dB |
| Return loss | ≥ 14 dB (-1.5 dB/Octave) |
| Noise figure typ. | ≤ 7 dB |
| Type | F-socket |
| power adapter | 230 VAC / 50 Hz |
| Operating display | LED |
| Power consumption | 6 W |
| Equipotential bonding connection | 4 mm² |
| Operating temperature range (according to EN 60065) | -20…+50°C |
| Dimensions (W × H × D) approx. | 160 × 100 × 45 mm |
| Weight | 0,488 kg |
| Protection class | IP20 |
Save More When You Buy More:
| 1-2items | £36.99/ each | |
| 3or more items | £35.14/ each | save5% |
